AYVAZ FGAV-20 Gate Vana API 602 1 1/2'' Class 1500
AYVAZ FGAV-20 Gate Valve API 602 1 1/2" Class 1500
Leak-Tightness at Extreme Pressure and Temperature with ORFA Industrial Assurance
The professional gate valve plays a critical role in high-pressure and high-temperature industrial applications, ensuring full control of liquid and gas flow while maximizing system safety. Designed by Ayvaz in accordance with API 602 standards, this gate valve is developed to meet the toughest conditions in petrochemical plants, refineries, and power plants operating in Class 1500 pressure class. Manufactured with an ASTM A182 F22 alloy forged steel body, the gate valve offers resistance to thermal fatigue under extreme temperature variations. Thanks to the Stellit 6 hard coating on the disc and seat surfaces, this gate valve reduces metal-to-metal friction wear to near-zero levels and promises long service life. Available from ORFA Industrial stock, this gate valve can be installed with a 1 1/2" (DN40) socket weld connection without interfering with standard piping systems. With a precision-machined wedge mechanism, the gate valve provides a leak-tight guarantee in the fully closed position and is a proven choice for critical energy circuits and oil processing lines. Each gate valve unit has passed rigorous industrial tests and fully complies with ASME B16.34 design standards. This gate valve, which you will prefer for high-pressure steam applications, ensures reliable performance while maintaining its structural integrity. Significantly reduce your operating costs with a gate valve that requires minimal maintenance after installation. Each gate valve unit is designed for continuous service up to 540°C. With this socket weld gate valve, prevent rust and ceramic deposits inside the pipe and maximize flow rate. Increase system efficiency with the Ayvaz gate valve, which can be safely used in refineries and the chemical industry.
Gate Valve Technical Specification Details
Key Advantages of the Gate Valve
- Leak-Tight Guarantee: Gate valve with ground disc and seat surfaces ensures full tightness.
- High Temperature Resistance: Alloy body structure resistant up to 540°C.
- Minimal Wear: Stellit 6 hard alloy coating reduces metal-to-metal friction wear.
- Full Standard Compliance: Gate valve fully compliant with API 602 and ASME B16.34 design standards.
Application Areas of the Gate Valve
- Gate valve used in high-pressure and high-temperature lines of petrochemical plants.
- Gate valve type preferred at main flow control points in refineries.
- Gate valve serving in steam and water piping systems of power plants.
- Gate valve installed to manage critical material flow in chemical industry reactors.
Discover safe flow control and long-lasting service in your high-pressure systems with Ayvaz gate valve solutions.
| Body Material | : | Cast Steel |
| Thread Size | : | 1 1/2'' |
