AYVAZ KV-18 Lug Tip Kelebek Vana DN40

AYVAZ KV-18 Lug Type Butterfly Valve DN40

Reliable Flow Control Solution with ORFA Industrial Assurance

The most effective method for flow control and pressure management in industrial pipelines is the lug type butterfly valve, which precisely regulates flow through a vertically positioned metal disc mechanism. This DN40 lug type butterfly valve, manufactured by Ayvaz, combines a GGG-40.3 ductile iron body and an aluminum bronze disc for high sealing and durability. Widely preferred in heating, ventilation, and water treatment systems, the professional lug type butterfly valve is the ideal solution for critical applications where low pressure loss is required. Manufactured with an AISI 420 stainless steel shaft and NBR seat, the lug type butterfly valve offers corrosion resistance and long operational life. Thanks to its wafer-type connection standard, this lug type butterfly valve can be installed directly between flanges, saving installation space and reducing system costs. Suitable for a maximum working pressure of 16 bar, the lug type butterfly valve operates safely between -10°C and 80°C. With a design suitable for lever operation, the lug type butterfly valve allows quick intervention in manual control applications and is also compatible with electric actuators. Available from ORFA Industrial stock, the Ayvaz KV-18 lug type butterfly valve operates reliably in demanding environments such as mining, agricultural systems, and industrial cooling towers. Each lug type butterfly valve unit is specially manufactured to perfectly fit DIN standard flange spacing. Elastic or plastic sealing elements, serving both disc-body connection and flange gasket, minimize maintenance and repair costs. Discover reliable flow control and maximum tightness in your pipelines with the quality Ayvaz lug type butterfly valve.

Discover safe flow control and long-lasting operation with AYVAZ lug type butterfly valve solutions.
