AYVAZ KV-3 Pnömatik Kelebek Vana DN25 PN16

AYVAZ KV-3 Pneumatic Butterfly Valve DN25 PN16

Reliable Flow Control Solution with the Assurance of ORFA Industrial

In industrial fluid control systems, the pneumatic butterfly valve provides reliable and precise management. The KV-3 model from Ayvaz offers high performance. This pneumatic butterfly valve has a nominal diameter DN25 and pressure class PN16, suitable for water, steam, gas and chemical lines. Made of GG-25 cast iron, the pneumatic butterfly valve guarantees durability, while the AISI 316 stainless steel disc and AISI 420 shaft provide superior corrosion resistance. With the H-EPDM sealing system, the pneumatic butterfly valve offers excellent tightness against high temperatures and chemicals, operating safely up to 130°C. The integrated double-acting pneumatic actuator reliably performs opening and closing with compressed air. This pneumatic butterfly valve allows easy integration thanks to actuator connection according to ISO 5211. The actuator with aluminum housing operates efficiently at 10 bar working pressure and in a temperature range of -20°C to +80°C. Supplied with the assurance of ORFA Industrial, this pneumatic butterfly valve provides long life and maintenance-free operation in industrial processes. Thanks to the wafer connection, the pneumatic butterfly valve is easily installed by clamping between flanges. Thus, the pneumatic butterfly valve facilitates maintenance and service. Each pneumatic butterfly valve is shipped after passing tightness tests. In conclusion, the pneumatic butterfly valve is an indispensable equipment for industrial plants.

Discover reliable performance in flow control with Ayvaz Pneumatic Butterfly Valve solutions.
