PAKKENS Automatic Boiler Filling Valve 1/2''

PAKKENS Automatic Boiler Filling Valve 1/2'': Safe and Automatic Control of Heating Systems

In closed circuit heating systems (combiator, boiler, radiator), the water level and therefore the pressure may decrease due to reasons such as pressure loss or air evacuation. This reduces the efficiency of the system and may cause malfunctions. To solve this problem automatically, PAKKENS Automatic Boiler Filling Valve comes into play. This valve is connected to the main water line of the installation, detects the pressure drop in the system and brings the water level to the desired level, ensuring that the system constantly remains at optimum pressure.

PAKKENS is one of Türkiye's leading manufacturers of pressure and temperature measurement equipment and has brought its expertise in this field to automatic control valves.

PAKKENS Technical Specifications of Automatic Boiler Filling Valve:

PAKKENS What is an Automatic Boiler Fill Valve and How Does It Work?

PAKKENS automatic boiler filling valve is a compact device that combines a water pressure sensor and an automatic control mechanism. Its connection diameter of 1/2 inç makes it ideal for domestic and small commercial heating systems.

Working Principle:

1. Pressure Sensing: The valve constantly monitors the instantaneous water pressure of the heating system to which it is connected.

2. Pressure Drop: When the water pressure in the system drops below the set minimum value (e.g. 1.5 bar) due to reasons such as leakage or deaeration, the control mechanism on the valve detects this drop.

3. Automatic Water Filling: When a pressure drop is detected, the valve automatically opens and starts filling the system with water from the mains water.

4. Pressure Stabilization: When the system pressure reaches the set maximum value (e.g. 2 bar), the valve automatically closes and water filling stops.

This automatic cycle ensures that the installation pressure always remains at the desired level, thus eliminating the need for manual intervention.

PAKKENS Advantages of Automatic Boiler Filling Valve:

• Automatic Control: It constantly monitors the installation pressure and eliminates the need for manual intervention by automatically filling water.

• Safe and Stable Operation: By keeping the system pressure in the ideal range (e.g. 0.5 – 4 bar ), it ensures efficient operation of the combi boiler and boiler and prevents malfunctions that may result from excessive pressure.

• Easy Adjustability: Desired minimum and maximum pressure values ​​can be adjusted on the valve.

• Integrated Manometer: Some models have an integrated manometer that instantly displays system pressure, making pressure monitoring easier.

• Check Valve Feature: There is a check valve inside the valve. This prevents the water in the heating system from escaping back into the mains line and increases the safety of the installation.

• Durable Material: Made of high quality pyrinç@@@@@@@@@@@@@@@@@@@@@@@@@@ Brass is resistant to corrosion and rust and offers long-lasting and reliable use.

• Compact Design: Thanks to its small dimensions, it can be easily installed next to the combi boiler or boiler.

• Wide Application Area: Suitable for domestic and commercial heating systems (combi boiler, boiler, solar energy systems).

PAKKENS Usage Areas of Automatic Boiler Filling Valve:

• Combi Boiler and Boiler Systems: Used to keep the water pressure of closed circuit heating systems constant.

• Solar Energy Systems: Controlling the pressure of water heated by solar energy.

• Hydrophore Systems: In automatic water filling of certain pressure tanks.

• Individual and Central Heating Systems: Managing water level and pressure in all closed circuit heating systems.

ORFA Reliable PAKKENS Solutions with Industrial

ORFA Endüstri Mamüller Sanayi ve Ticaret A.Ş. As, we offer the highest quality PAKKENS automatic boiler filling valves for the safe and efficient operation of your heating systems. With the quality of PAKKENS and the expertise of ORFA, we are at your service to ensure the long life and trouble-free operation of your systems.
