Pedrollo TOP 3 Submersible Drain Pump: The Reliable Solution for Residential and Commercial Drainage Needs

Pedrollo is a globally recognized brand in the pump industry, renowned for its Italian engineering quality. The Pedrollo TOP 3 submersible drainage pump is a compact, lightweight, and durable submersible drainage pump designed for the rapid and efficient drainage of clean or slightly contaminated water from basements, garages, rainwater collection points, cisterns, and wells.

What is the Pedrollo TOP 3 Submersible Drain Pump and What Does It Do?

A submersible drainage pump is a type of pump that operates completely submerged in water. The Pedrollo TOP 3 model designates this submersible drainage pump as ideal for clean water (drainage) applications. The pump's electric motor is housed in a water-resistant housing, ensuring quiet and efficient operation while submerged.

Main Functions of Submersible Drainage Pump:

• Water Drainage: Provides rapid drainage of water accumulated in places such as basements, garages, cisterns and rainwater pools.

• Automatic Operation: An integrated float switch automatically activates and deactivates the pump according to the water level. This prevents the pump from running dry and increases system safety.

• Tank and Well Transfer: Can be used to draw water from water tanks or shallow wells.

• Circulation: Can be used to provide water circulation for fountains or small pools.

Highlights and Advantages of Pedrollo TOP 3 Submersible Drainage Pump:

• High Performance: It has a motor power of 0.75 kW ( 1 HP ). Its maximum flow rate is 260 liters/minute ( 15.6 m³/hour ), and its maximum head can reach up to 11 meters .

• Durable Structure: Pump body, impeller and suction grille are manufactured from corrosion-resistant technopolymer (glass fiber reinforced plastic).

• Stainless Steel Shaft: The pump shaft is made of stainless steel (AISI 431), which ensures long-lasting use.

• Automatic Float Switch: The float automatically starts the pump when the water level rises and stops it when the water level drops. This feature prevents the pump from running out of water.

• Compact and Lightweight Design: Weighing only 6.6 kg, it can be easily carried and used in narrow spaces.

• Low Suction Level: It can suction even when the water level drops to 30 mm. In manual mode, it can drain almost completely (water level drops to 14 mm).

• Thermal Protection: The motor has thermal protection that protects it from overheating.

• Wide Application Area: Suitable for the discharge of clean water (particle size < 10 mm) and slightly polluted water.

Areas of Use of Pedrollo TOP 3 Submersible Drainage Pump:

• Domestic Applications: Flooded basements, garages, elevator pits.

• Construction Industry: Discharge of slightly polluted water.

• Garden and Pool: Emptying ornamental pools, water transfer.

• Agriculture: Irrigation systems, rainwater collection tanks.

• Wells and Cisterns: Clean water supply and transfer.
