Pedrollo TOP 3 VORTEX Dalgıç Drenaj Pompası 0.75 HP

Pedrollo TOP 3 VORTEX Submersible Drainage Pump: Fast and Effective Discharge of Dirty Water

Pedrollo is a globally recognized brand in the pump industry, renowned for its Italian engineering quality. The Pedrollo TOP 3 VORTEX submersible drainage pump is a compact, lightweight, and durable submersible drainage pump designed for the rapid and efficient drainage of dirty water from basements, garages, cisterns, and wells, as well as liquids containing suspended solids up to 25 mm in diameter .

What is the Pedrollo TOP 3 VORTEX Submersible Drainage Pump and What Does It Do?

A submersible drainage pump operates by being completely submerged in water. The Pedrollo TOP 3 VORTEX model designates this pump as ideal for dirty water applications. Unlike traditional drainage pumps, its VORTEX impeller allows it to easily handle solid particles.

Main Functions of Submersible Drainage Pump:

• Dirty Water Discharge: Quickly removes water from wastewater, drainage and sewer systems.

• Automatic Operation: Automatically activates and deactivates according to the water level with an integrated float switch .

• Tank and Well Transfer: Can be used to draw water from water tanks or shallow wells.

• Continuous Service: Designed for S1 operating mode.

Highlights and Advantages of the Pedrollo TOP 3 VORTEX Submersible Drainage Pump:

• High Performance: It has a motor power of 0.55 kW ( 0.75 HP ). Its maximum flow rate is 170 l/min (10.2 m³/h) and its maximum head can reach up to 8.7 meters .

• Durable Construction: The pump body, impeller, and suction filter are made of fiberglass-reinforced technopolymer . The motor housing is made of AISI 304 stainless steel , and the motor shaft is made of AISI 431 stainless steel .

• VORTEX Type Impeller: Can process suspended solids up to Ø25 mm in diameter .

• Automatic Float Switch: The float automatically starts the pump when the water level rises and stops it when the water level drops. This feature prevents the pump from running out of water and extends its life.

• Compact and Lightweight Design: Easily portable with a weight of only 6.8 kg.

• Low Suction Level: Suction level is 35 mm above the ground.

• Thermal Protection: The motor has thermal overload protection integrated into the winding.

• Wide Application Area: It is used in a wide range of applications from domestic to civilian use.
