Pneumatic Actuated Stainless Steel Ball Valve 1/2''
DN15 | AISI 304 Grade | Double Acting Actuator | Full Port
The 1/2'' pneumatic actuated stainless steel ball valve is a professional assembly designed for fully automatic on-off control in industrial fluid lines. Featuring an AISI 304 cast body, this stainless steel ball valve offers superior resistance in acidic and corrosive environments. The high-torque pneumatic actuator enables this stainless steel ball valve to operate quickly and reliably at 6 bar air pressure. With a full port internal design, the stainless steel ball valve minimizes pressure loss during flow, enhancing system efficiency. Preferred in the food, chemical, and pharmaceutical industries, the stainless steel ball valve stands out for its hygienic and durable construction. Equipped with long-lasting sealing elements, the stainless steel ball valve can be safely used in the most demanding automation projects. Investing in a quality stainless steel ball valve reduces your maintenance costs.
TECHNICAL SPECIFICATIONS
Size / Nominal Diameter: 1/2'' - DN15 Stainless Steel Ball Valve
Body Material: AISI 304 Stainless Steel
Actuator Type: Pneumatic Double Acting / Spring Return Optional
Connection Type: Threaded Stainless Steel Ball Valve
Sealing: PTFE (Teflon) Sealed Stainless Steel Ball Valve
Working Pressure: PN40 - PN63 Rated Stainless Steel Ball Valve
Temperature Range: -20°C to +180°C Stainless Steel Ball Valve
INSTALLATION AND USE
- Use of stainless steel ball valve in lines requiring fast switching.
- Stainless steel ball valve fully compatible with actuators via ISO 5211 top flange.
- Stainless steel ball valve integrable with solenoid valve and limit switch box.
- Easy-to-disassemble and clean design of stainless steel ball valve.
ADVANTAGES
- High corrosion resistance of stainless steel ball valve structure.
- Fully compatible with industrial automation performance of stainless steel ball valve.
- Safe control of challenging fluids (acids, steam, oils) with stainless steel ball valve.
- Efficient stainless steel ball valve operation with low torque requirement.
| Thread Size | : | 1/2'' |
