Valbia 8P01590007 Pnömatik Aktüatörlü Pirinç Küresel Vana 1 1/4'' PN40

Valbia 8P01590007 Pirinç Ball Valve with Pneumatic Actuator 1 1/4" PN

ORFA Industrial Products Industry and Trade Inc. We are proud to offer reliable and high-performance solutions for your industrial flow control needs. Valbia brand's pneumatic actuated pirinç ball valve, code 8P01590007, provides precise control and durability in various applications with its 1 1/4" (DN32) size and PN40 pressure class.

This Actuated Pirinç Ball Valve is a combination of Rubinetterie Bresciane Bonomi 2500040000 ball valve and Valbia DA32 double acting pneumatic actuator.

Pirinç Ball Valve with Actuator Features:

Bonomi 2500040000 Ball Valve:

• Material: Pirinç body (CW617N UNI EN 12420), Pirinç sphere (CW617N UNI EN 12165)
• Nickel Plating: Increases corrosion resistance.
• Full Bore: Low pressure loss and high flow capacity.
• BSP Threaded Connection: Easy installation.
• Operating Temperature: -20°C to +160°C.
• Gaskets: PTFE, FKM, EPDM (suitability for different applications)
• ISO 5211 Compatible: Standard connection surface for actuator mounting.

Valbia DA32 Pneumatic Actuator:

• Double Action: Fast and precise control, remote control possibility.
• Aluminum Body: Light and durable.
• Hard Anodized Coating: Extra protection and durability.
• Visual Position Indicator: Easy monitoring.
• Pneumatic Connections: /8" BSP.
• Travel Stoppers: Bi-directional open/close.
• Gaskets: NBR (-20°C / +85°C), VITON (-20°C / +150°C) or SILICONE (-40°C / +85°C) options.
• Air Supply Pressure: Maximum 8 Bar.
• Standards: ATEX II 2GD T6, ISO 5211, DIN 3337, NAMUR.
• Specifications:
  • mm star driver mount
  • +/- 5° stroke adjustment
  • Patented travel stop adjustment cam
  • Antistatic device

Pirinç Ball Valve with Actuator Usage Areas:

• Chemical and petrochemical industry
• Food and pharmaceutical industry
• Water and wastewater treatment
• HVAC systems
• Automation systems

Valbia Pneumatic Actuated Ball Valve:

• High Performance: Precise control and reliable operation.
• Durability: Material and construction resistant to harsh conditions.
• Safety: Safe use in explosive environments with ATEX certification.
• Efficiency: Low pressure loss and energy saving.
• Versatility: Wide range of applications.

ORFA As Industrial Products, you can contact us to get detailed information about our Valbia 8P01590007 Pneumatic Actuated Pirinç Ball Valve and our other Actuated Pirinç Ball Valve solutions. Our expert team will be pleased to offer the most suitable solutions for your needs.
