ARI FABA Plus 23.046 Metal Bellows Valve PN25 DN20
%55 Discounted Product
0 - Comment / Read Comments
507,60 EUR
228,42 EUR
Category
Brand
Stock Code
708A050500502
Warranty Period
24 Month
Price
423,00 EUR + VAT
* Installments starting from 228,42 EUR!
Add to Cart
ARI FABA Plus 23.046 Metal Bellows Valve PN25 DN
ARI FABA Plus 23.046 Metal Bellows Valve is an industrial valve solution designed for high safety and long-lasting use. Thanks to its double-layered metal bellows structure, it maximizes sealing performance and minimizes the need for maintenance. This valve provides reliable and efficient flow management, especially in the control of steam, hot water and aggressive fluids. ORFA This Metal Bellows Valve, offered for sale by Endüstri Mamüller Sanayi ve Ticaret A.Ş. , is one of the most suitable options for heavy industrial conditions.
Metal Bellows Valve Working Principle
Metal bellows valves use a seal with a bellows structure to control fluid passage. The double-layer stainless steel bellows flex in accordance with the fluid pressure, allowing the valve to open and close. This design offers higher sealing security than classic stuffing box valves. In addition, equipment such as rotation lock, grease fitting and mechanical stroke indicator increase the ease of use of the valve and enable the operator to instantly monitor the operating status.
Technical Specifications
Body-Cover: EN-JS1049 Ductile Iron
Bellow: .4571 (AISI316Ti) Double Layer Stainless Steel
Clapper: Marginal seat (conical)
Seat and Flap: .4021+QT (AISI 420) Stainless Steel
Equipments: Grease nipple, Rotation Lock, Mechanical Stroke Indicator
Flywheel: DN ≤125 Pressed Steel / DN > EN-JL1040 Cast Iron
Test Standard: EN ISO 15848-1 / TA-Luft TÜV approved (Test-No: TA 07 2016 C04)
Connection Type: Flanged
Maximum Operating Temperature: °C
Pressure Class: PN
Nominal Diameter: DN
Usage Areas of Metal Bellows Valve
Steam Lines and Boiler Systems
Petrochemical and Refinery Facilities
Power Plants
Heating and Cooling Facilities (HVAC Systems)
Chemical Process Industry
Fluid lines operating under high temperature and pressure
ARI FABA Plus 23.046 Metal Bellows Valve PN25 DN20 provides maximum efficiency and reliability in industrial facilities with its long-lasting metal bellows structure and high safety standards. ORFA Industrial Products Industry and Trade Inc. This product, offered for sale by , has passed internationally certified tests and stands out with its suitability for heavy working conditions.
| Diameter-Dn | : | DN 20 |
| Body | : | Ductile Iron |
| Pressure Class | : | PN 25 |
