Flow Control Valve
The Flow Control Valve we sell at ORFA Industrial Products Industry and Trade Inc. is a high-quality product designed to precisely control water flow and is used in a variety of industrial applications. Operating with mains pressure, this valve maintains a constant flow rate without requiring additional energy and is unaffected by fluctuations in pressure and flow at the valve inlet. It also increases efficiency by preventing water waste, particularly during backwashing in filtration systems.
Product Features:
It works with mains pressure and does not require additional energy.
Provides easy and precise adjustment to the desired flow rate.
Provides long-lasting use with easy maintenance
Technical Information:
Body: GGG40 Ductile Iron
Diaphragm: Cord Fabric Reinforced Natural Rubber
Cover: GGG40 Ductile Iron
Diaphragm Pressure Ring: Polyamide
Spring: SST 302
Max. Working Pressure: 16 bar
Max. Operating Temperature: 80 ºC
Connection Type: Flanged
Areas of Use:
Flow Control Valves are designed for use in a variety of industrial and commercial applications. They are commonly used in water treatment and filtration systems, irrigation systems, HVAC (Heating, Ventilation, and Air Conditioning) applications, and industrial water distribution systems. These valves offer an environmentally friendly solution by preventing water waste, particularly in backwashing processes, and help businesses reduce their water costs.
Adjustment and Assembly:
Install the signal hose and orifice plate supplied with the valve on the line as shown in the user manual. Set the 3-way ball valve on the valve to the Auto position. Open the protective cover of the 3-way pilot valve on the valve. If the flow through the valve is insufficient, increase it by tightening the adjustment screw. For excessive flow, loosen the adjustment screw. The valve can be installed in either a horizontal or vertical position, providing flexibility and adapting to various installation needs.
