AYVAZ PV-16 Piston Valve Pn16 Dn40
0 - Comment / Read Comments
AYVAZ PV-16 Piston Valve PN16 DN40 Highest Level in Tightness – Reliable Flow Control in Compact Lines It is a valve model with a durable body structure and high sealing performance, offered with the assurance of ORFA Endüstri Mamüller Sanayi ve Ticaret A.Ş.
, used for cutting and controlling the fluid in the lines. This model, with a diameter of DN40, offers a safe and long-lasting solution, especially in small diameter systems. GGG40 ductile iron body provides high mechanical strength and impact resistance, while the sealing is maximized thanks to the stainless piston system and gaskets. Suitable for operation in the PN16 pressure class, the PV-16 model has a wide range of uses, from heating-cooling systems to steam, water and various process fluids.
Model:
PV-
, used for cutting and controlling the fluid in the lines. This model, with a diameter of DN40, offers a safe and long-lasting solution, especially in small diameter systems. GGG40 ductile iron body provides high mechanical strength and impact resistance, while the sealing is maximized thanks to the stainless piston system and gaskets. Suitable for operation in the PN16 pressure class, the PV-16 model has a wide range of uses, from heating-cooling systems to steam, water and various process fluids.
Model:
PV-
Nominal Diameter: DN
Body Material: GGG40 Ductile Iron
Cover: GGG40 Ductile Iron
Flywheel: AISI 304 Stainless Steel + Graphite
Piston: .4104 Stainless Steel
Connection Type: Flanged
Piston: .4104 Stainless Steel
Connection Type: Flanged
Pressure Class: PN
Operating Temperature: -10°C to +300°C
Usage Type: Manual control (optional automation)
Leakage Class: High, maintainable structure
Piston Valve Usage Areas: Heating and cooling systems
Process water lines
Process water lines
Steam and condensate lines
Food and chemical industry
Industrial automation systems
Compressed air and liquid lines
AYVAZ PV-16 GGG40 Piston Valve, offered with the assurance of ORFA Endüstri Mamüller Sanayi ve Ticaret A.Ş.
, providing fluid control in compact systems, high tightness and It is a durable, long-lasting valve solution.
AYVAZ PV-16 GGG40 Pistonlu Vana, ORFA Endüstriyel Mamüller Sanayi ve Ticaret A.Ş. güvencesiyle sunulan, kompakt sistemlerde akışkan kontrolü sağlayan, yüksek sızdırmazlık ve dayanıklılığa sahip, uzun ömürlü bir vana çözümüdür.
AYVAZ PV-16 GGG40 Pistonlu Vana, ORFA Endüstriyel Mamüller Sanayi ve Ticaret A.Ş. güvencesiyle sunulan, kompakt sistemlerde akışkan kontrolü sağlayan, yüksek sızdırmazlık ve dayanıklılığa sahip, uzun ömürlü bir vana çözümüdür.
| Diameter-Dn | : | DN 40 |
| Body | : | Ductile Iron |
| Pressure Class | : | PN 16 |
