GEVAX 7901-KDVB016-020-24DC Paslanmaz Solenoid Valf 1/4''
0 - Comment / Read Comments
Stokta yok
Category
Brand
Stock Code
7901-KDVB016-020-24DC
Warranty Period
24 Month
Request a Quote
You can send us any questions you have about technical support, product information, or general topics. Our experts will get back to you as soon as possible.
GEVAX Solenoid Valve Stainless NK 1/4'' 7901-KDVB016-020-24DC High Temperature Resistant, Stainless Body Direct Pull Solenoid Valve
GEVAX 7901-KDVB016-020-24DC is a solenoid valve specially developed for industrial automation and flow control applications with its stainless steel body and high temperature resistance. This valve, with a 1/4" connection diameter and 2/2 paths, provides a safe and leak-proof flow management with its normally closed (N.C.) position. Thanks to its direct-pull design, it can operate with minimum 0 bar pressure and shows effective performance even in low flow systems. The FKM gasket and diaphragm used in the valve are between -10°C and +150°C wide Provides high chemical resistance in the temperature range. It offers fast response time and energy efficiency thanks to the Amisco brand 10W coil that works with V DC voltage. Thanks to its compact structure and light weight of 0.41 kg, it provides convenience in both panel and on-line mounting.
Solenoid Valve Technical Specifications:
GEVAX 7901-KDVB016-020-24DC is a solenoid valve specially developed for industrial automation and flow control applications with its stainless steel body and high temperature resistance. This valve, with a 1/4" connection diameter and 2/2 paths, provides a safe and leak-proof flow management with its normally closed (N.C.) position. Thanks to its direct-pull design, it can operate with minimum 0 bar pressure and shows effective performance even in low flow systems. The FKM gasket and diaphragm used in the valve are between -10°C and +150°C wide Provides high chemical resistance in the temperature range. It offers fast response time and energy efficiency thanks to the Amisco brand 10W coil that works with V DC voltage. Thanks to its compact structure and light weight of 0.41 kg, it provides convenience in both panel and on-line mounting.
Solenoid Valve Technical Specifications:
Model: 1-KDVB016-020-24DC
Connection Size: /4"
Valve Type: Stainless Valve
Number of Paths: /
Position: Normally Closed (N.O.)
Operating Principle: Direct Pull
Gasket & Diaphragm Material: FKM
Min. Working Pressure: bar
Max. Working Pressure: bar
Orifice Diameter: mm
Operating Temperature: -10°C ~ +150°C
KV Value: .7 l/min
Coil Brand: Amisco
Coil Voltage: V DC
Coil Power: W
Coil Type: TP
Body Material: Stainless Steel
Body Code: OC
Weight: .41 kg
Solenoid Valve Usage Areas:
Solenoid Valve Usage Areas:
Chemical liquid and gas flow control
Industrial process lines
Heating-cooling systems
Water purification and dosing systems
Food and pharmaceutical industry
Automation systems and panels
GEVAX 7901-KDVB016-020-24DC 1/4" Stainless Solenoid Valve offers reliable solutions in chemical and industrial systems with its high temperature and pressure resistant structure. Direct pull-on It provides effective control even in low flow applications with its mechanism.
GEVAX 7901-KDVB016-020-24DC 1/4" Stainless Solenoid Valve offers reliable solutions in chemical and industrial systems with its high temperature and pressure resistant structure. Direct pull-on It provides effective control even in low flow applications with its mechanism.
| Özellik | Değer | |
|---|---|---|
| Operating Voltage | : | 24 V DC |
| Thread Size | : | 1/4'' |
