MAXTOR 4R210-08 Manual Slide Valve 5/2 1/4 ''

MAXTOR 4R210-08 Manually Operated Slide Valve: Reliable Directional Control in Pneumatic Systems

Manually operated slide valves are used to manually direct the flow of compressed air in industrial automation and pneumatic machinery. The MAXTOR 4R210-08 Manually Operated Slide Valve is a practical valve designed to meet this need, featuring a 5/2 (5-way, 2-position) structure and a 1/4" threaded connection.

This valve allows you to quickly and reliably control the reciprocating motion of pneumatic cylinders and other double-acting pneumatic equipment.

What is MAXTOR 4R210-08 and What Does It Do?

MAXTOR 4R210-08 is a directional control valve installed in the air supply line of a pneumatic system and controlled by means of a manual lever.

• 5/2-Way Valve: This valve has five ports (one inlet, two outlets, and two exhausts) and two positions. It is ideal for controlling a double-acting pneumatic cylinder; in one position, air flows into one side of the cylinder and exhausts the other; when the valve is moved to the other position, this process is reversed.

• Hand Operated: Operated by a manual control such as a lever or button. This allows the valve to be controlled directly by the machine operator.

• Slide Valve: The main moving part inside the valve is a slide (piston). The movement of this slide directs airflow.

Highlights and Advantages of MAXTOR 4R210-08:

• Manual Control: Can be controlled manually by the operator without the need for electrical power. This is particularly suitable for applications requiring safety or simple control.

• Wide Operating Range: It can operate in a wide operating pressure range of 0-10 bar .

• Durable Construction: The body is made of durable aluminum die-casting material. Stainless steel internal parts and NBR sealing elements ensure long-lasting and reliable performance.

• Easy Installation: 1/4'' threaded connection is compatible with many standard pneumatic systems.

• Versatility: Suitable for fluids such as compressed air, vacuum and neutral gases.

Areas of Use:

• Industrial Machinery: Manual control on all machines containing pneumatic cylinders such as presses, cutting machines, conveyors.

• Workshops and Factories: Control of air-powered tools.

• Pneumatic Control Panels: For manual control of pneumatic circuit in control panels.

• Assembly Lines: Pneumatic applications requiring direct worker intervention in production and assembly lines.
