Siemens LME 22.233C2 Burner Control Unit: Safe and Efficient Combustion Management
The Siemens LME 22.233C2 Burner Control Unit, offered by ORFA Industrial Products Industry and Trade Inc. , is a high-tech control unit designed to ensure safe and optimized gas burner operation. It offers maximum performance and reliability for use with two-stage gas burners of small and medium capacities, with or without fans. This innovative device provides a high level of user convenience by controlling all processes, from automatic burner start-up to monitoring and safe shutdown.
Siemens LME 22.233C2 Burner Brain Working Principle
The Siemens LME 22.233C2 Burner Control Unit fully automates burner start-up, monitoring, and shutdown. Its operating principle includes the following steps:
Pre-Purge: The air in the combustion chamber is cleaned before the burner is started.
Ignition: A safe ignition process is carried out.
Flame Control: Continuous monitoring is done with ionization probes or flame detectors.
Thanks to advanced safety features such as low voltage detection, air pressure monitoring and color indicators for error notifications, the system intervenes immediately in the event of any malfunction.
Siemens LME 22.233C2 Burner Brain Product Features
Working Principle: Supports single or two-stage gas or gas/liquid fuel burners.
Flame Control: Compatible with ionization probe, blue flame detector or QRA AGQ3...A27 model detector.
Compliance with Standards: Full compliance with EN 298:2003, EN 676 and EN 230:2005 standards.
Low Voltage Detection: Minimizes security risks.
Air Pressure Control: Provides functional control of air pressure switches during operation.
Remote Reset: Remote reset option for easy troubleshooting.
Color Fault and Operation Display: User-friendly interface.
Intermittent Operation: System security is ensured with automatic intermittent operation after 24 hours of continuous use.
Siemens LME 22.233C2 Burner Brain Technical Specifications
Model: LME 22.233C2
Stage: Two Stages
Control: Servo Controlled
Voltage/Frequency: 220 V - 50/60 Hz
Power Consumption: 12 VA
Safety Time: 3 seconds
Pre-Sweep Time: 20 seconds
Protection: IP40
Storage Conditions: Temperature resistance between -20°C and +60°C and relative humidity tolerance <95%.
Siemens LME 22.233C2 Burner Brain Usage Areas
Heating Systems: The ideal solution for central heating systems in commercial and industrial buildings.
Boilers: Provides safe burner control in hot water and steam boilers.
Drying Plants: Suitable for burner management in industrial drying processes.
Furnaces: Increases combustion efficiency and safety in industrial furnaces.
Siemens LME 22.233C2 Burner Brain Safety and Warnings
Basic warnings that must be taken into account to ensure safe operation of the device and to minimize the risk of malfunction:
Do not tamper with the unit and ensure that only qualified personnel perform the installation.
Ensure all electrical connections are properly insulated.
Check whether there is a short circuit in the connecting lines of the air pressure switch.
Never put the device into operation if it has been dropped or impacted.
The Siemens LME 22.233C2 Burner Control Unit offers a safe, efficient, and sustainable solution with its superior technology that meets the requirements of modern industrial processes. This product, offered by ORFA Industrial Products Industry and Trade Inc. , ensures operational excellence by operating your systems safely and efficiently. Contact us for more information and to purchase our product.
